AMFA-300-24
AMFA-300-24
Model: AMFA-300-24
Power: 300W, (60W/ 100W/ 150W/ 200W/ 250W Optional)
Output Voltage: 24V
Input Voltage: 176-264V
Efficiency: ≥90%
Lifespan: 100000 Hours
IP Rating: IP20
Rated Current: 12.5A
Operating Temperature: -40~+70°C
Dimensions: 248x 51x 27.5mm
Warranty: 3 years
Power: 300W, (60W/ 100W/ 150W/ 200W/ 250W Optional)
Output Voltage: 24V
Input Voltage: 176-264V
Efficiency: ≥90%
Lifespan: 100000 Hours
IP Rating: IP20
Rated Current: 12.5A
Operating Temperature: -40~+70°C
Dimensions: 248x 51x 27.5mm
Warranty: 3 years
Quantity:
Specification | Dimensions(mm) | ||||||||||||||||||||
|  |
Product Features
- A series of linear lighting switching power supplies offering a full range of rated power levels, with brightness adjustable via DIP switches to 50%, 75%, or 100%.
- This series utilizes a semi-potting encapsulation process and is specifically designed for indoor linear lighting, LED neon strips, and other advertising light boxes.
- Compact in size, aesthetically pleasing when installed, and saving on shipping costs and storage space.
- High efficiency and excellent heat dissipation greatly improve product reliability and extend product lifespan.
- Multi-protection (OVP/ OCP/ OLP/ SCP/ OTP). Auto shut-off on short circuit for enhanced safety.
Product Structure
 | Key Features: An intelligent linear lighting switching power supply equipped with DIP switches that allow you to set the brightness to 50%, 75%, or 100% based on the environment and your personal preferences. Simply connect the input and output cables, plug it in, and it’s ready to use. DIP Switches Used | |||
 |  |  |  | |
soft-start functionality | 50% Brightness | 75% Brightness | 100% Brightness | |
Caution:Do not disassemble this unit. Installation and use must be performed by a licensed electrician, and the power must be turned off before any work is performed.
Applications
1. Outdoor signage, illuminated lettering for light boxes, and lighting projects for parks, public spaces, and buildings.
2. Lighting for indoor retail storefront displays, ambient lighting for entertainment venues, home décor, and linear lighting fixtures.
 |  |  |  |  |
Hotel Lighting Projects | Smart Lighting for Furniture | Indoor Linear Lighting | Bars, KTVs, and Leisure Clubs | Storefront Lighting |
 |  |  |  |  |
Outdoor Playgrounds | Bridge & Building Lighting Projects | Indoor Supermarket Advertising | Advertising Signs | Illuminated Letters and Light Boxes |
Product installation instructions and precautions:
1. Before powering on and testing after installation, please check and verify that the inputs and outputs, AC and DC, positive and negative terminals,
voltage and current values are correct. Prevent reverse connection or incorrect connection to avoid damaging the power supply and user equipment.
2. Before powering on, please use a multimeter to check whether the live wire, neutral wire, and ground wire are short-circuited, and whether the output
terminal is short-circuited; it is best to start under no-load when powering on.
3. Do not exceed the power supply's rated values during use, as this may affect product reliability. If you need to change the power supply's output
parameters, please consult our technical department before using the power supply to ensure optimal performance and reliability.
4. To ensure safety and reduce interference, please ensure that the grounding terminal is reliably grounded
